Simulation production line demonstration experimental device

Author： Time：2024-03-14 Hits：

Simulation production line demonstration experimental device,Automotive Electric Light Evaluation System Experimental Device

The tr--ning device is conducted by the model guide r--l tr--ning table, typical electromechanical integrated equipment mechanical components, PLC modules, inverter modules, button modules, power modules, simulation production equipment tr--ning modules (including materials units, belt delivery detection units, pneumatic pneumatic The robot handling unit, the material transmission of the storage unit and the return unit), the touch screen, the wiring terminal row, and various sensors. The open and disassembly structure is adopted, and production equipment can be assembled according to the existing mechanical parts, so that the entire device can be flexibly assembled by tr--ning or competition to assemble the optical and electrical integrated equipment with production functions. The module adopts industrial standard structure and drawer module placing frame, which has strong interchangeability.

The tr--ning system integrates motion control, pneumatic control, frequency frequency speed regulation, step motor drive, servo motor driver, sensor detection, programmable control, timing logic control. Based on the use, tr--ning and tr--ning based on the tr--ning system, we can fully exercise the operator team collaboration ability, planning organization ability, automatic line installation and debugging capabilities, and engineering implementation capabilities. At the same time, it is suitable for students to design and graduate design.

1. Technical performance

1. Enter power supply: three -phase and four lines (or three -phase and five lines) ~ 380V ± 10% 50Hz

2. Working environment: temperature -10 ℃ ～+40 ℃ relative humidity ≤ 85%(25 ℃) Altitude <4000m

3. Device capacity: <1.0kva

4. Dimensions: 1200mm × 800mm × 1500mm

Second, equipment equipment

M--nly from the profile tr--ning table, the material unit, the belt conveyor transport detection unit, the pneumatic machine handling unit, the material transmission storage unit, the material return unit, the PLC module, the inverter module, the button module, the power module, various sensors, the touch screen, the material , I/O interface boards and trachea composition, complete the feed, detection, sorting, handling, transmission, classification, storage, and return to the initial position.

Tr--ning program

Task 1: Installation and debugging of pneumatic systems

(1) Control the installation of the circuit in the direction of the pneumatic direction

(2) Installation of pneumatic speed control circuit

(3) Installation of aerodynamic sequence control circuit

(4) Installation of pneumatic robotics

Simulation production line demonstration experimental device(图1)

Simulation production line demonstration experimental device,Automotive Electric Light Evaluation System Experimental Device

1. Product introduction

The device is based on the physical object of the vehicle's external lighting system to fully display the structure and working process of the car's external lighting system.

It is suitable for the school's teaching needs for car lighting system theory and m--ntenance tr--ning.

2. Functional characteristics

1. After the system component is inserted, the real -operated vehicle external lighting system is fully displayed to fully display the composition of the car's external lighting system.

2. Manipulate the switch to realize the work process of the car's external lighting system.

3. The teaching board panel adopts a ** aluminum -plastic board with strike, pollution resistance, fire prevention, and moisture -proof, and spray primer p--nt on the surface by special crafts; school students can intuitively control the work and analyze the work of the automotive lighting system in accordance with the circuit diagram and physical objects. principle.

4. Detective terminals are installed on the teaching board panel, which can directly detect the electrical signals of the circuit components of the vehicle's external light system on the panel, such as resistance, voltage, current, frequency signals, etc.

5. Demonstration panel parts use 1.5mm cold plate stamping and forming structure, beautiful appearance; the ch--n part is welded with steel structure, the surface is treated with spraying process, a self -locking wheel device, and a desktop on the base of the teaching plate. , Easy to place data, light detection instruments, etc.
