Power battery pack and BMS management system experimental device



The device is based on the real objects of the battery and its management BMS system to display the structure and work process of the battery and the management of the BMS system. The components are reduced by proportional simulation components and real parts, and the battery and their management BMS system experimental box are made. Excellent st--nless steel handles are installed in the box, which is convenient for carrying and launching teaching.



2. Functional characteristics



1. Real -operated battery and its management BMS system, displaying the composition of battery and its management BMS system.



2. Manipulate switches, etc., you can truly demonstrate the work process of battery and its management BMS system.



3. The panel adopts a ** aluminum -plastic plate with strike, pollution resistance, fire prevention, and moisture -proof, and the surface is sprayed with primer p--nting by special crafts. Students can intuitively control the working principles of the circuit diagram and physical objects to understand and analyze the control system.



4. The detection terminal is installed on the panel, which can directly detect the electrical signals of the circuit elements of the system on the panel, such as resistance, voltage, current, frequency signals, etc.



5. The box part uses a 4mm aluminum plastic plate structure with a beautiful appearance.



6. Work adopts ordinary 220V AC power supply.

7. Machinery assembly and fitter assembly virtual simulation software: This software is developed based on Unity3D. It can select 6 -level image quality. It has the design and virtual disassembly of the reducer and shaft structure, the design and simulation of common mechanical institutions, institutional resource libraries, institutional resource libraries. Typical mechanical institutions (virtual disassembly of gasoline engines), software is an overall software, which cannot be separate resources.



A. Turbine design and virtual disassembly interface can be selected from turbine sn--l pole cone gear reducer, second -level pilot gear reducer, conical cylindrical gear reducer, coaxial cylindrical gear reducer, cone gear reducer, first -class cylindrical, first -class cylindrical, Gear reducer.

1. Product introduction

The device is based on the physical object of the vehicle's external lighting system to fully display the structure and working process of the car's external lighting system.

It is suitable for the school's teaching needs for car lighting system theory and m--ntenance tr--ning.



2. Functional characteristics

1. After the system component is inserted, the real -operated car external lighting system is fully displayed to fully display the composition of the car's external lighting system.

2. Manipulate the switch to realize the work process of the car's external lighting system.

3. The teaching board panel adopts a ** aluminum -plastic board with strike, pollution resistance, fire prevention, and moisture -proof, and spray primer p--nt on the surface by special crafts; school students can intuitively control the work and analyze the work of the automotive lighting system in accordance with the circuit diagram and physical objects. principle.

4. Detective terminals are installed on the teaching board panel, which can directly detect the electrical signals of the circuit components of the vehicle's external light system on the panel, such as resistance, voltage, current, frequency signals, etc.

5. Demonstration panel parts use 1.5mm cold plate stamping and forming structure, beautiful appearance; the ch--n part is welded with steel structure, the surface is treated with spraying process, a self -locking wheel device, and a desktop on the base of the teaching plate. , Easy to place data, light detection instruments, etc.
