Hydraulic lifting car flip training device

Author： Time：2024-02-19 Hits：

Hydraulic lifting car flip tr--ning device,Manual transmission disassembling experimental device

1. Function Introduction

1. Use the 2016 Cruze 1.4T electronic control gasoline engine assembly (easy to disassemble) and assemble it on a special engine disassembly and turning rack.

2. Adopting a deceleration flip mechanism can rotate the engine at any angle and lock at any position, so that students can disassemble and assemble from different angles.

3. Place a large area of oil disk at the bottom to facilitate the centralized storage of small parts or screws.

4. Disassembling rotation racks are welded with high -intensity steel structures, and the surface is sprayed with spraying process. The bottom has a self -locking wheel device, which can be moved to facilitate teaching.

5. Hydraulic lifting device, high adjustment range of 0-200 mm, and has a safe lock function.

two. Technical specification

Equipment shape: 1200 × 600 × 1100mm (long × width × height)

Color: 7032

Steel pipe: 40*40*3mm

Universal foot wheel

The first two universal band lock function foot wheels

2 After the two thousand -facing foot wheels

The foot wheel and the table frame are fixed with the M6*4 screws, which is convenient for equipment m--ntenance and m--ntenance.

Foot wheel: 60mm × 50mm (diameter × width)

Foot wheel support: 1.0T

Hydraulic lifting car flip tr*ning device(图1)

Hydraulic lifting car flip tr--ning device,Manual transmission disassembling experimental device

(1) Use a manual transmission assembly and install it on a special flipper.

(2) Rotate the gear transmission at any angle and lock it at arbitrarily to facilitate disassembly and assembly from different angles.

(3) Place the oil disk at the bottom to facilitate the centralized storage of small parts or screws.

(4) The turning rack is welded with high -intensity steel structure, and the surface is treated with spraying process. There is a self -locking foot wheel at the bottom of the flipper, which can move.

(5) Dimensions: 1000 × 600 × 1100mm (length × width × height)

Basic configuration (each)

Serial number, name, specification model, unit, quantity

1. Anatomy manual transmission assembly, renovation, set, 1

2. The turning rack (with a self -locking wheel device), 950 × 680 × 850mm (long × width × height), T--wan, 1
