UNITANK Bioswater Treatment Experimental Device

1. Experimental purpose:

1. Strengthen the understanding of the operation method of integrated water biological treatment.

2. Master the measurement method of integrated water biological treatment.

3. Deepen the process and technical data of the device.

2. Experimental principle:

Use a combination of biological and materialized. The biological treatment uses the 40 polypropylene ball to flow the contact oxidation that is easy to flow. The two sink ponds use the oblique tube to settle the tank, and then filter and disinfect the standard of water in the water.

2. M--n technical indicators and parameters:

1. Environmental temperature: 5 ℃ ～ 40 ℃

2. Treatment of water: 20-30L/H,

3. Device shape size: 2400mm × 500mm × 1500mm,

4. Work power: AC220V ± 10%, 50Hz, single -phase three -line system, power 800W, safety protection: ground protection, leakage protection, overcurrent protection

3. M--n configuration:

1. 1 original water tank: white PP plate material, 10mm thickness, 500 × 400 × 500mm, empty valve installed on the bottom plate, which is convenient for cleaning the water;

2. 1 water collection sink, white PP plate material, 10mm thickness, 400 × 350 × 400mm, empty valve installed on the bottom plate, which is convenient for cleaning the water;

3. 1 water tank: white PP plate material, 10mm thick, 400 × 350 × 400mm, empty valve is installed on the bottom plate, which is convenient for cleaning the water;
